CB4 22mm Metal Type Push button Switch

Short Description:

CB series pushbutton switches are used in industrial for controlling circuits of AC 50Hz or 60Hz,rated operation voltage 380V or below and DC operational Voltage 220V or below for controlling in magnetic,starter,contactor,relay and other electrical circuits.The buttons indicators can also be used in the place with indicated light or signal.They compatible with the standards:IEC60947-5-1.

Send email to us

Product Detail

Product Tags

Application

CB*- series pushbutton switches are used in industrial for controlling circuits of AC 50Hz or 60Hz,rated operation voltage 380V or below and DC operational Voltage 220V or below for controlling in magnetic starter、contactor、relay and other electrical circuits. The buttons indicators can also be used in the place with indicated light or signal. They meet with the standards :IEC60947-5-1.

Man Technical Parameter

Operation temperature: -5℃~+40℃	Power-frequency withstand voltage: 2500V, 1min
Operation humidity: 45%~85%	ELECTRIC durability: 50×104
Contact resistance: ≤50mΩ	Degree of protection: Ip40
Rated insulation voltage	Ui 660V
Conventional thermal current	Ith 10A
Rated operation voltage	Ue 380V 220V 110V 48V 24V
Rated operation current	AC-15	2.5A	4.5	6A	8A	-
Rated operation current	DC-13	-	0.3A	0.6A	1.3A	2.5

Rated operational Voltage	Directness						Resistance		Transformer
Rated operational Voltage	6V	12V	24V	48V	110V	220V	380V	220V	220V	380V
LED lamp	√	√	√	-	-	-	-	-	√	√
Neon lamp	-	-	-	-	√	√	√	√	-
Incandescence lamp	√	√	√	√	√	√	√	-	√	√
